光伏モジュールシミュレーション試験室 定量化容量

光伏モジュールシミュレーション試験室 定量化容量

ブランド名: Envsin
モデル番号: ESR
Moq: 1セット
価格: $8000 >=1 Set
支払条件: L/C、D/A、D/P、T/T、ウェスタン・ユニオン
供給能力: 1ヶ月あたりの30セット
詳細情報
起源の場所:
広東省
証明:
ISO CE
テスト容積:
1500L その他 定番
軽い波長:
フルバンドスペクトル,太陽光 280nm~3000nm
パワー:
AC380V 50Hz/60Hz 3/N/P
保証:
1 年
供給の能力:
1ヶ月あたりの30セット
ハイライト:

ISOの太陽放射テスト部屋

,

多目的太陽放射テスト部屋

,

多目的紫外線老化するテスト部屋

製品説明
全スペクトルを持つ太陽シミュレーション試験室

太陽光発電simulation test chamber can be used to evaluate the thermal or photo-chemical ability of equipment that is directly exposed to solar radiation during the hot season of life to withstand solar radiation. ユーザーは,色,形状,強度,様々な熱膨張結果を含む,放射線を受けた後,部品や車両の性能の変化を評価し,車両の起動性能をテストすることができます.,太陽光照射下での運動性能およびその他の指標
わたしたち の 奉仕

• 総合的な試験ソリューションを提供 (カスタマイズ)

• 中国におけるAppleとCiscoの優先サプライヤー

•販売前および販売後の体系的な技術支援
Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 0
仕様





温度 テスト
放射線温度範囲なし: -40°C+120°C
放射線温度範囲: -20°C+100°C
温度均一性: ≤ 1.5°C
温度偏差: ± 2.0°C
温度変動: ±0.5°C
熱速: ≥5°C/分
冷却速度: ≥2°C/分





温度と気候試験

温度範囲:+20°C+85°C
湿度範囲:10% RH 〜98% RH
温度均一性:≤ 1.5°C
湿度均一性:3. 0% RH
温度偏差:±2.0°C
湿度偏差: +2/ほら3%RH
温度変動: ±0.5°C
湿度変動: ±2.0% RH


太陽放射線試験
紫外線露出面積>5600cm2
光波長:全帯域スペクトル,太陽光 280 nm から 3000 nm
放射線強度: ((0 ~ 1200) W/m2を調整し,試験中に継続的に記録することができます.
性能曲線図
Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 1




照明の全スペクトル画像

基準:


• 医療機関IEC60068-2-5 試験SA: 表面太陽放射線のシミュレーション


• 医療機関DIN75220 日光シミュレーターにおける自動車部品の交換

• 医療機関MIL-STD 810G 環境工学関連事項と実験室試験
Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 2




温度と湿度曲線図

• 医療機関温度:+20°C+85°C

• 医療機関温度均一性:≤1.5°C

• 医療機関湿度均一性:30.0%RH

温度変動:±0.5°C

湿度変動:±2.0%RH




Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 3
